2500w Power Inverter

Real loading 2500w power inverter design with 5000w peak power with soft start function,high performance for various types:cars,electronic vehicles,boat,light,fans. Reliable quality inverters are popular on the global market for green energy and portable power.he inverters must pass the standard process of produce with strict test and related lab test such as vibration test,low & high temperature alternating test,salty spray test and Hi-Pot Test for safety operation.

Product parameter(Specification) of the 2500w power inverter

Modified Sine Wave Inverter
■ Modified sine wave output;■ High surge power up to 2 times of real loading power;■ Loading 1.5times rated power for 10s,2times for 2s;■ High efficiency up to 92%;■ Power ON-OFF switch;■ Soft start;■ Built-out fuse;■ More stable working functions■ Front panel indicator for operation status;■ Thermostatically and load controlled cooling fan;■ Protections:Bat. low alarm/Bat. low shutdown/Bat. over shutdown/output short/input reverse protection/overload/over Temp.■ 18 months wattanty
MODELKS2500M-112KS2500M-124KS2500M-148KS2500M-212KS2500M-224KS2500M-248
OUTPUTRATED POWER2500W
SURGE POWER5000W
AC VOLTAGEFactory setting set at 100V/110V/120V ACFactory setting set at 220V/230V/240V AC
FREQUENCY50Hz/60Hz optional
WAVE FORMModified sine wave
AC REGULATION±10%
STANDARD RECEPTACLESSchuko/UK/Australia/Universal/USA/France/JP/Brazile
FRONT PANEL INDICATOROperation and fault status
INPUTBAT.VOLTAGE12V24V48V12v24V48V
VOLTAGE RANGE9.7-16.4VDC19.4-32.8VDC38.8-65.6VDC9.7-16.4VDC19.4-32.8VDC38.8-65.6VDC
DC CURRENT300A150A75A300A150A75A
NO LOAD CURRENT DRAW<0.9A<0.78A<0.69A<0.9A<0.78A<0.69A
EFFICIENCY89%>90%92%88%90%91%%
BATTERY TYPESRecommend use Open & sealed lead acid battery
BATTERY INPUT PROTECTIONBAT.LOW ALARM10.8±0.3V21.6±0.6V43.2±1.2V10.8±0.3V21.6±0.6V43.2±1.2V
BAT.LOW SHUTDOWN10±0.3V20±0.6V40±1.2V10±0.3V20±0.6V40±1.2V
BAT.OVER SHUTDOWN16±0.4V32±0.8V64±1.6V16±0.4V32±0.8V64±1.6V
REVERSE POLARITYyes
OUTPUT PROTECTIONOVER TEMPERATURE≥45ºC or ≥60% rated power, cooling fan open;≥70ºC,Shut off.
Protection type : Shut down o/p voltage, re-power on to recover; by internal Thermistor detect on heatsink of power transistor
OUTPUT SHORTProtection type:Shut down o/p voltage;re-power on to recover
OVER LOAD100%-120% rated load for 10 sec.
Protection type : Shut down o/p voltage, re-power on to recover; by internal Thermistor detect on heatsink of power transistor
ENVIRONMENTWORKING TEMP.-15℃～+40℃@100% load;60℃ @50% load
WORKING HUMIDITY20%90% RH non-condensing
STORAGE TEMP.-30℃～+70℃/-22℉～+158℉
STORAGE HUMIDITY10%95% RH non-condensing
SAFETYCECompliance to EN55032
LVDCompliance to EN60950-1
ROHSCompliance to EN50581
E-MARKE13
OTHERSISO9001/IATF16949/BSCI
UL testB08H52NN2M/ B08H54PCDT/ B08H4TMTJC/ B08H51DTM8
REACHNo.:1907/2006
certificate of registrationIATF 16949:2016111458/A/0001/SM/En
OTHERSUSB port5V/2.1A
DIMENSION L*W*H (mm)320*220*90
PACKING(cm)45.5*30.5*36 ;2pcs/CTN,12.8KG

Product feature and application of the 2500w power inverter

①. Fuse:built-out;

②. USB:5V/2.1A;

③. Modified sine wave output;

④. High reliability and high efficiency;

⑤. High load ability;

⑥. Temperature Controlled Cooling Fan;

⑦. Protection:Overload.Short Circuit,Reverse Polarity,Over/Under Input Voltage,Over Temperature;

⑧. LED Indicator light indicate inverter,fault mode;

⑨. CE/RoHS/E-Mark/ISO9001 approved.

Product Qualification of the power inverter

A. CE Compliance to EN55032

B. RoHS Compliance to EN50581

C. LVD Compliance to EN60950-1

D. E-Mark E13

E. IATF 16969

F. REACH/UL/TUV report

Deliver,Shipping And Serving of the power inverter

It is a flexible transportation for the power inverter to clients such as express/train/ocean/air etc which could meet different customers choice.The factory manage the materials in advance after confirming the order,and then,produce the cargoes which save more time for the whole process.KOSUN inverter pack with customized color box or neutral packages according to the customer demands.

FAQ

A. What character of the manufacture?

KOSUN are one of professional manufacture with two factories built in 2011 which equip with advanced auto-machine and modern assembly line for the standard process of produce,the products are more stable for the long time operation.The main products include pure sine wave inverter,inverter with charger,modified sine wave inverter,battery charger and power station etc,thus,welcome to negotiate with us for more information you want.

B. Why your quotation is higher than other suppliers?

C. In domestic market, the high and low inverter brands are mixed together. There are many low-cost inverter is actually some assembled small unlicensed workshops, it crudely, to reduce costs and use of substandard components for assembly, there is a very big security risk! In order to protect the pro personal and property safety, please do not covet low price, be sure to choose a reliable inverter;

D. Is the output voltage of our inverter stable ?

E. Absolutely. Our inverter is designed with a good regulator circuit. You can even check it when measuring the true value by a multimeter. Actually the output voltage is quite stable;

F. What is a resistive load appliances?

G. Generally speaking, appliances like mobile phones, computers, LCD TVs, incandescents, electric fans, video broadcast, small printers, electric mahjong machines, rice cookers etc. All belong to resistive loads. Our modified sine wave inverters can drive them successfully.

H. What is the inductive load appliances?

I. It refers to the application of electromagnetic induction’s principle, produced by high-power electrical products, such as motor type, compressors, relays, fluorescent lamps, electric stove, refrigerator, air conditioner, energy saving lamps, pumps, etc. These products’power are far more than the rated power (about 3-7 times) when start. So only pure sine wave inverter is available to them.

The advantages to choose our team:

1. Our sales staff has extensive sales experience through continuous training and practice which they have the ability to efficiency cooperate development between company and clients and provide satisfied service to customers;

2. The company buy modern equipment for automated production line;

3. Training professional technical staff is essential process to improve the quality of produce;

4. Meeting before order production determine relative details to reduce error output;

5. Strict quality control(incoming inspection/semi-finished product inspection/finished product test/several times full test on-line/sampling test before shipment);

6. OEM/ODM accept by workshop;

7. Good after-sales service for long-term development.
